Technical outline Formula 4 Tatuus F.4 T 014
Chassis
Tatuus monocoque carbon composite
FIA F.4 homologated
Saefty features
Carbon composite front and rear crashbox FIA F.4 homologated
Steering column FIA F.4 homologated
Roll-hoop FIA F.4 homologated
Wheel tethers Cortex FIA homologated
OMP Six-point safety harnesses, Hans system OMP Extinguisher electrically operated
Removable head protection
Removable seat FIA standard
Bodywork
Fiberglass
Wings
Front wing with mainplane adjustable
Rear wing with two aero profiles adjustable
Engine
Fiat Abarth Turbo 1.4 cc. 160 cv.
Electronics ECU
Magneti Marelli
Instrumentation
Display LCD integrato al volante Next Solution
Data acquisition
AIM Evo 4 inclusa camera car
Transmission
Sequential Sadev six-speed gearbox
Paddle shift Magneti Marelli EGA
Front Suspension
Double wishbone with pushrods
Twin shock layout
Camber and toe adjustable
Rear Suspension
Double wishbone with pushrods
Twin shock layout
Camber, toe, roll centre, anti-squat adjustable
Dampers
Oram Bump e rebound regolabili
Brakes
Brembo 2 pistons calipers, cast iron ventilated discs Ferodo brake pads
Fuel
Premier FIA FT3 fuel cell compatible, 40 lt. volume
Tires
Pirelli front 200 x 540 x 13” rear 250 x 575 x 13”
Wheels
O.Z Aluminium front 8 x 13” rear 10 x 13”
Dimension
Wheelbase: 2750 mm
Front track: 1510 mm
Rear track: 1460 mm
